£798.48
excl. VAT
£958.18 incl. VAT
£958.18
incl. VAT
£798.48 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Displacement | 315 cm³/rev |
|---|---|
| Drain port thread diameter | 1/4 Inch |
| Drain port thread type | G |
| Flange code | SAE-A |
| Flange shape | Oval |
| Housing length | 181.5 mm |
| Main port thread diameter | 1/2 Inch |
| Main port thread type | G |
| Max. continous working pressure | 70 BAR |
| Max continuous torque | 300 N·m |
| Max. flow rate | 60 l/min |
| Max intermittend working pressure | 100 BAR |
| Max. power | 5 kW |
| Max pressure peak | 150 BAR |
| Max rotation speed | 190 r/min |
| Min rotation speed | 5 r/min |
| Number of mounting holes | 4 |
| Original number equivalent | 1516017 |
| Product details | With leak oil drain, Roller design, Wide shaft plain bearing, Can be connected in series with other motors, Suitable for use in closed systems, Belongs to the series of medium-sized orbital motors |
| Rotor length | 54.8 mm |
| Sealing type | Standard |
| Shaft diameter | 25 mm |
| Shaft type | Straight parallel |
| Unit | Each |
