£858.16
excl. VAT
£1,029.79 incl. VAT
£1,029.79
incl. VAT
£858.16 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Displacement | 375 cm³/rev |
|---|---|
| Drain port thread diameter | 1/4 Inch |
| Drain port thread type | G |
| Flange code | SAE-A |
| Flange shape | Oval |
| Housing length | 191.7 mm |
| Main port thread diameter | 1/2 Inch |
| Main port thread type | G |
| Max. continous working pressure | 115 BAR |
| Max continuous torque | 580 N·m |
| Max. flow rate | 60 l/min |
| Max intermittend working pressure | 150 BAR |
| Max. power | 7.5 kW |
| Max pressure peak | 175 BAR |
| Max rotation speed | 160 r/min |
| Min rotation speed | 5 r/min |
| Number of mounting holes | 4 |
| Original number equivalent | 1516008 |
| Product details | With leak oil drain, Roller design, Wide shaft plain bearing, Can be connected in series with other motors, Suitable for use in closed systems, Belongs to the series of medium-sized orbital motors |
| Rotor length | 54.8 mm |
| Sealing type | Standard |
| Shaft diameter | 32 mm |
| Shaft type | Straight parallel |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 10150 g |
| Dimensions | 285 × 135 × 115 mm |
| Dangerous goods | No |
