£860.54
excl. VAT
£1,032.65 incl. VAT
£1,032.65
incl. VAT
£860.54 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Displacement | 200 cm³/rev |
|---|---|
| Drain port thread diameter | 1/4 Inch |
| Drain port thread type | G |
| Flange shape | Short |
| LHousing length | 145 mm |
| Long description | Orbital motors are distinguished by their compact construction, large axial, radial shaft loads and high starting torque. |
| Main port thread diameter | 1/2 Inch |
| Main port thread type | G |
| Max. continous working pressure | 210 BAR |
| Max continuous torque | 610 N·m |
| Max. flow rate | 75 l/min |
| Max intermittend working pressure | 250 BAR |
| Max. power | 16.5 kW |
| Max pressure peak | 270 BAR |
| Max rotation speed | 375 r/min |
| Min rotation speed | 6 r/min |
| Number of mounting holes | 4 |
| Original number equivalent | 151F0539 |
| Product details | Short motor, Without shaft bearing, Without output shaft, Very short design, Particularly suitable for continuous use in tough conditions, High continuous operating pressure, Very smooth running at low speeds, Frequent reversing possible, High efficiency, Excellent start-up properties |
| Rotor length | 34.8 mm |
| Sealing type | n/a |
| Shaft diameter | 27.6 mm |
| Shaft number of teeth | 12 |
| Shaft type | Splined |
| Unit | Each |
Compatible accessories
Parts and components that work with this product.
OMS9AFDV
White Seal kit OMS/VITON 151F OMS9AFDV
£79.97 excl.
£95.96 incl.
OMSS9AFD
White Gasket set 151F0103 OMSS9AFD
£47.76 excl.
£57.31 incl.
RF289
Reggiana Ruduttori Brake disc RF2 89 OMS RF289
£1,037.41 excl.
£1,244.89 incl.
VADDF10001
Walvoil Relief val 10 A 08 OMS A 1/2" VADDF10001
£125.49 excl.
£150.59 incl.
VANT12OMS
Walvoil Check valve VANT T 12-OMS VANT12OMS
£71.36 excl.
£85.63 incl.
VODLSCAF10001
Walvoil Counterbalance A-08-OMS 1/2BSP VODLSCAF10001
£323.75 excl.
£388.50 incl.
VODLSCF10001
Walvoil Counterbal A-08-OMS-A-4 1/2" VODLSCF10001
£306.14 excl.
£367.37 incl.
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 9505 g |
| Dimensions | 400 × 177 × 162 mm |
| Dangerous goods | No |
