Product details
| Displacement | 11 cm³/rev, 8 cm³/rev |
|---|---|
| Flange and back cover material | Cast iron |
| Flange code | N |
| Flange type norm | German |
| Housing material | Aluminium |
| Max. continous working pressure | 250 BAR, 250 BAR |
| Max intermittend working pressure | 160 BAR, 90 BAR |
| Max pressure peak | 185 BAR, 100 BAR |
| Max rotation speed | 4000 r/min |
| Min rotation speed | 800 r/min |
| Mounting diameter | 50 mm |
| Mounting holes horizontal distance | 60 mm |
| Mounting holes vertical distance | 60 mm |
| Number of mounting holes | 2 |
| Original number equivalent | R918C01207, 3146446R94, 0510565314, 0510565311 |
| Port position | Side |
| Pressure port bolts circle diameter | 35 mm |
| Pump group code | 2 |
| Rotation direction | Counter-clockwise (CCW) |
| Sealing material | Viton |
| Sealing type | Standard |
| Shaft cone size code | 1:5 |
| Shaft diameter | 17 mm |
| Shaft thread diameter | M12 |
| Shaft thread pitch | 1.50 mm |
| Shaft thread type | Metric |
| Shaft type | Tapered 1:5 |
| Shaft type code | C |
| Suction port bolts circle diameter | 40 mm |
| Suitable for machine/vehicle brand | Claas, New Holland |
| Unit | Each |
| Weight | 4.85 kg |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 5500 g |
| Dimensions | 250 × 130 × 90 mm |
| Dangerous goods | No |
