£769.70
excl. VAT
£923.64 incl. VAT
£923.64
incl. VAT
£769.70 excl. VAT
Free shipping
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Application | Telescopic |
|---|---|
| Application range | Tipping cylinder for vans, Small to medium-sized trailers |
| Benefits | High efficiency, Save time during assembly, Excellent running properties |
| Cylinder material | Steel MW450U/E470 |
| Details | Light, modern design, Completely assembled unit, Tenifer TF1 coated plungers |
| Long description | Telescopic Cylinder series K " Kompakt" |
| Max. capacity at 180 bar | 10 t |
| Max. working pressure | 200 BAR |
| Max. working temperature | 110 °C |
| Min. length | 450 mm |
| Min. mounting holes distance | 561 mm |
| Min. working temperature | -40 °C |
| Mounting type - cylinder side connection | Bore |
| Mounting type - rod side connection | Bore |
| Number of stages | 4 |
| Oil capacity | 9 l |
| Outside diameter | 124 mm |
| Piston surface roughness range | 0.20-0.20 µm |
| Properties | High durability and long service life |
| Sealing material | Polyurethane |
| Stroke | 1510 mm |
| Unit | Each |
| Weight | 39 kg |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 30000 g |
| Dimensions | 630 × 145 × 145 mm |
| Dangerous goods | No |
