Kramp V-belt pulley 1 groove B or SPB diameter 243mm for taperlockbush 2012 236B1TL

About this product

A single-groove V-belt pulley with 243 mm outside diameter and 236 mm pitch diameter, designed for B and SPB profile V-belts with 17 mm width. The pulley is manufactured from cast iron and features a taperlock bore (type 2012) that accommodates shaft diameters up to 50 mm, enabling use with different shaft sizes. The hub measures 104 mm in diameter with 32 mm width and 3.5 mm offset positions. The working width is 32 mm with a chamber diameter of 193 mm. Maximum operating speed is 30 m/s. The pulley is supplied without a taperlock adjustment bush, which must be ordered separately. It is designed for application in construction machines, forestry machinery, agricultural machinery, and mechanical engineering. Supplied as a single piece weighing approximately 4.2 kg. Overall dimensions are 245 mm length, 245 mm width, and 32 mm height. The product carries EAN 4014486247176 for inventory matching. The taperlock design allows rapid assembly and disassembly without tools.
