Product details
| Connection 2, thread diameter | 3/4 Inch |
|---|---|
| Connection 2, thread length | 24 mm |
| Connection thread diameter | M40 |
| Connection thread length | 17 mm |
| Connection thread pitch | 1.50 mm |
| DTotal height | 150 mm |
| Max. flow rate | 80 l/min |
| Max working pressure | 250 BAR |
| Mounting possibility | Suited for in-line mounting |
| Sealing material | Viton |
| Technical info | These valves are fitted with a graduated turning knob, which is standard. Independent of the load, the pressure compensator provides a constant volume flow. |
| Total width (diameter) | 163 mm |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 3466 g |
| Dimensions | 170 × 150 × 60 mm |
| Dangerous goods | No |
