£45.03
excl. VAT
£54.04 incl. VAT
£54.04
incl. VAT
£45.03 excl. VAT
In stock
Expected to ship on Monday 5 October
Policy information
Delivery
Shipped on a 24–48 hour service from the expected ship date, unless stated otherwise. Next day delivery is available on selected items. Free over £120.00 incl. VAT, otherwise £4.80.
Delivery informationSecure payment
3D Secure card checkout — we never store your card details.
Product details
| Body height | 41 mm |
|---|---|
| Connection 1, thread diameter | M45 |
| Connection 1, thread pitch | 2.00 mm |
| Connection 1, thread type | Metric |
| Connection 1, type | Thread |
| Connection 1, type - male/female | Male |
| Connection 2, diameter | 35 mm |
| Connection 2, length | 34.5 mm |
| Connection 2, thread diameter | M45 |
| Connection 2, thread pitch | 2.00 mm |
| Connection 2, thread type | Metric |
| Connection 2, type | Thread |
| Connection 2, type - male/female | Male |
| Connection 2, wrench/spanner size | 50.0 mm |
| Connection 3, diameter | 35 mm |
| Connection 3, thread diameter | M45 |
| Connection 3, thread pitch | 2.00 mm |
| Connection 3, thread type | Metric |
| Connection 3, type | Thread |
| Connection 3, type - male/female | Male |
| Connection no 1 center to end distance | 34.5 mm, 45 mm |
| Connection no 1 diameter | 35 mm |
| DIN standard | 2401, 2353 |
| Inside diameter | 30 mm |
| Max working pressure | 250 BAR |
| Pipe diameter | 35 mm |
| Product details | Direct connection with a metric hose gland or pre-mounted coupling, Multiple corrosion resistance, Hydraulic hose, Hydraulic pipes |
| Pros | Reduced risk of leakage |
| S1Connection no 1 wrench size | 50.0 mm |
| Series | L |
| Shape | Tee (T) |
| Surface treatment | Nickel-plated, Zinc |
| Total length | 90 mm |
| Unit | Each |
Compatible accessories
Parts and components that work with this product.
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 539 g |
| Dimensions | 91 × 67 × 45 mm |
| Dangerous goods | No |
You might also like
BPA000287816
Voss Cutting ring coupling with hex, 10L — 1/4 BSPT GES10LRK14
£6.86 excl.
£8.23 incl.
In stock
Expected to ship on Monday 5 October
BPA000310393
Voss L coupling 6S R1/4 LEV6SRK14
