£1,342.19
excl. VAT
£1,610.63 incl. VAT
£1,610.63
incl. VAT
£1,342.19 excl. VAT
Free shipping
In stock
Expected to ship on Friday 18 September
Product details
| Connection thread diameter | 1-1/4 Inch |
|---|---|
| Cooling medium flow type | Suction |
| Depth | 208 mm |
| Fan outside diameter | 280 mm |
| Includes | Aluminium radiator, Support, Impeller/electric motor, voltage according to version, Temperature switch, Connector for connecting temperature switch/DC motor |
| Insulation class | 68 |
| Long description | Oil coolers or heat exchangers are used to increase the exchange of heat between oil and ambient air. The coolers come as standard with a 38-50°C thermostat. A controlled oil temperature increases the efficiency and lifetime of the components in the system. |
| Material | Plastic, Aluminium, Steel |
| Max. working flow | 180 l/min |
| Max. working pressure | 20 BAR |
| Noise level | 79 dB(A) |
| Nominal voltage | 24 V |
| Product details | Temperature switch 38-50°C, Maximum temperature 120°C, The motor must be switched via a relay, The OK2050 is equipped with two fans in the 12VDC and 24VDC versions |
| Pros | Compact flush mounting, Complete unit, Increased efficiency, Long component service life |
| Technical info | Oil coolers are used to improve the heat exchange between the oil and the environment. The coolers are fitted as standard with a thermostat 40-48ºC. |
| Thermostat working temperature | 38 - 50 |
| Unit | Each |
| Weight | 24 kg |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 32000 g |
| Dimensions | 670 × 640 × 250 mm |
| Dangerous goods | No |
