£43.84
excl. VAT
£52.61 incl. VAT
£52.61
incl. VAT
£43.84 excl. VAT
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Basic radial load dynamic | 20600 N |
|---|---|
| Basic radial load static | 12900 N |
| Bearing model type | Angular contact ball bearings |
| BWidth | 20.6 mm |
| Contact angle | 30 ° |
| dInside diameter | 20 mm |
| DOutside diameter | 47 mm |
| Inside diameter of outer ring | 40.1 mm |
| Manufacturer | Schaeffler |
| Max rotation speed | 10000 r/min |
| Max working temperature | 120 °C |
| Min working temperature | -20 °C |
| Original number equivalent | 3204-BD-XL-2Z-TVH |
| Outside diameter of inner ring | 29.22 mm |
| Radial internal clearance code | CN |
| Ref rotation speed | 14700 r/min |
| Regreasable | No |
| Rows number | 2 |
| Sealing | ZZ |
| Surface treatment | n/a |
| Unit | Each |
| Weight | 0.152 kg |
Logistics
| EAN | 40128024746644064327676214 |
|---|---|
| Unit of measure | EA |
| Weight | 155 g |
| Dimensions | 50 × 50 × 25 mm |
| Dangerous goods | No |
