Product details
| Angle | 30 ° |
|---|---|
| Groove width | 5.6 mm |
| Inside diameter | 85 mm |
| Long description | These 10E/GTP guide rings are made from cotton fabric reinforced with phenolic resin, providing a strong and reliable solution for guiding rods and pistons in hydraulic systems. They ensure proper alignment, absorb lateral forces, and protect against metal-to-metal contact. Their durable build safeguards both shaft and housing from wear, making these bearing rings ideal for mobile and heavy-duty applications with high surface pressures. |
| Material guide ring | Synthetic |
| Outside diameter | 90 mm |
| Piston-guiding | Yes |
| Product details | Guide rings for pistons and rods of hydraulic cylinders, Piston rod guidance, Prevents metallic contact, Suitable for high loads, Low friction, Material : Cotton fabric, reinforced with phenolic resin, Maximum sliding speed : 1 m/s, Temperature range : -30°C till 120°C, Cutting angle : 30° |
| Rod-guiding | No |
| Type | Guide ring, Piston guiding |
| Type code | 10E/GTP |
| Unit | Each |
| Width | 5.6 mm |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 1 g |
| Dimensions | 90 × 90 × 6 mm |
| Dangerous goods | No |
