£537.50
excl. VAT
£645.00 incl. VAT
£645.00
incl. VAT
£537.50 excl. VAT
Free shipping
In stock
Expected to ship on Tuesday 22 September
Product details
| Displacement | 100 cm³/rev |
|---|---|
| Drain port thread diameter | 1/4 Inch |
| Drain port thread type | G |
| Flange code | SAE-A |
| Flange shape | Oval |
| Housing length | 144.5 mm |
| Main port thread diameter | 1/2 Inch |
| Main port thread type | G |
| Max. continous working pressure | 175 BAR |
| Max continuous torque | 240 N·m |
| Max. flow rate | 60 l/min |
| Max intermittend working pressure | 200 BAR |
| Max. power | 13 kW |
| Max pressure peak | 225 BAR |
| Max rotation speed | 600 r/min |
| Min rotation speed | 10 r/min |
| Number of mounting holes | 2 |
| Original number equivalent | 1510243 |
| Product details | With leak oil drain, Roller design, Wide shaft plain bearing, Can be connected in series with other motors, Suitable for use in closed systems, Belongs to the series of medium-sized orbital motors |
| Rotor length | 17.4 mm |
| Sealing type | Standard |
| Shaft diameter | 32 mm |
| Shaft type | Straight parallel |
| Unit | Each |
Compatible accessories
Parts and components that work with this product.
FPRF90DVD2R12OMR
FluidPress Flow control valve 3-Way OMP/R/H FPRF90DVD2R12OMR
£264.03 excl.
£316.84 incl.
MDVOMR12
Walvoil Dir. control valve for OMP/OMR MDVOMR12
£248.19 excl.
£297.83 incl.
OMP9WP
Unbranded Welding plate OMP OMR OMS OMP9WP
£23.61 excl.
£28.33 incl.
OMR9AFD32
White Seal Kit 151-1166 OMR9AFD32
£67.88 excl.
£81.46 incl.
VAIF05001
Walvoil Relief valve A-08-OMP-C-1/2" BSP VAIF05001
£82.08 excl.
£98.50 incl.
VANT40OMR
Walvoil Check valve VANT/40/OMP-OMR VANT40OMR
£49.66 excl.
£59.59 incl.
VODLSCAF05001
Walvoil Counterbalance valve A-08-OMR- 1/2BSP VODLSCAF05001
£259.30 excl.
£311.16 incl.
VODLSCF05001
Walvoil Counterbal A-08-OMR-A-4 1/2" VODLSCF05001
£260.41 excl.
£312.49 incl.
VPR3EP10005
Walvoil Flow control valve 3-Way OMP/R VPR3EP10005
£186.92 excl.
£224.30 incl.
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 7848 g |
| Dimensions | 300 × 165 × 160 mm |
| Dangerous goods | No |
