£1,142.41
excl. VAT
£1,370.89 incl. VAT
£1,370.89
incl. VAT
£1,142.41 excl. VAT
Free shipping
Out of stock — Backorder available
Usually ships within 3–8 weeks.
Product details
| Displacement | 375 cm³/rev |
|---|---|
| Drain port thread diameter | 1/4 Inch |
| Drain port thread type | G |
| Flange diameter | 106.4 mm |
| Flange shape | Oval |
| Main port thread diameter | 1/2 Inch |
| Main port thread type | BSP |
| Max. continous working pressure | 70 BAR |
| Max continuous torque | 360 N·m |
| Max. flow rate | 60 l/min |
| Max intermittend working pressure | 175 BAR |
| Max. power | 5 kW |
| Max rotation speed | 155 r/min |
| Min. starting pressure | 5 BAR |
| Min. starting torque | 345 N·m |
| Mounting holes circle diameter | 82.5 mm |
| Number of mounting holes | 2 |
| Port position | Side |
| Product details | With leak oil drain, Roller design, Wide shaft plain bearing, Can be connected in series with other motors, Suitable for use in closed systems, Belongs to the series of medium-sized orbital motors |
| Sealing type | Standard |
| Shaft diameter | 25 mm |
| Shaft type | Splined |
| Unit | Each |
Logistics
| EAN | — |
|---|---|
| Unit of measure | EA |
| Weight | 10030 g |
| Dimensions | 300 × 160 × 165 mm |
| Dangerous goods | No |
